Wet EFI Nitrous Plate Camaro LS3 2010-2015 90 mm 4-Bolt (plate only)

The NOS "Plate Only" kit allows our customers to build a custom nitrous system for their 2010-2015 Chevrolet Camaro, or any application using a GM LS style, 90mm, 4-bolt throttle body. This ultra-slim design is only 1/4" thick at the throttle body mounting flange. This allows maximum room forward of the throttle body to clear accessory drives, tensioner brackets or other obstacles that may interfere with a more forward mounted throttle body.

This kit includes a 6061 billet aluminum, black anodized nitrous plate, assembled and ready to bolt on, stainless socket head bolts, 8 NOS stainless jets to support power levels of 75, 100, 125 & 150 rear wheel horsepower increases.

Key features

• Single 1/4" plate between the throttle body and manifold
• Throttle body mounts in stock orientation
• Supports up to 250 RWHP (Rear Wheel Horse Powe PI)
• Includes jetting for 75, 100, 125, & 150 RWHP
• New plate outlet design maximizes distribution
• 6061 Billet Aluminum, CNC Machined Plate
• Also available as a complete kit for the 2010-2015 LS3 Camaro; p/n 05160NOS

Technical specifications

• Brand: NOS (Nitrous Oxide System PI)
• Manufacturer part number: 13436NOS
• Jet type: Flare
• System type: Wet
• Maximum power: 250 HP
• Jetting included for: 75, 100, 125, 150 HP
• Delivery style: EFI Spacer Plate
• Plate flange / bolt pattern: GM 4-Bolt LS3
• Plate mounting: 4 bolt
• Plate diameter: 90 mm
• Plate thickness: 1/4 in (6.3 m PI)
• Adjustable: Yes
• Bottle included: No
• Colour: Black
• Material: 6061-T6 Aluminum
• Plate included: Yes

Good to know

• Retains stock throttle body location and orientation using a 1/4" billet aluminum plate. Ideal for any LS, 90mm, 4-bolt application. Supports up to 250 Horsepower

Important: this product runs on nitrous oxide (N2 PI), a gas we do not supply and which is currently difficult to obtain. It is your responsibility to find a local supplier of gas for professionals. NOS bottles do not comply with CE standards (they do not carry the PI mark): only CE-approved bottles may be used. European manufacturers offer bottles approved to contain this gas; please check the applicable standards and verify the manufacturer's origin and compliance before purchasing. NOS fittings are not metric (AN / NPT threads depending on the part numbe PI): plan for the adapters needed for your installation. Please comply with the regulations in force in your country.
